Description
| Network Port | 4, 100Mbps; RJ45 ports; Max. 30W Output of Single PoE Port Transmission distance:0~250m |
| Uplink Ports | 2, 100Mbps, Transmission Distance: 0-100m |
| Switch Capacity | 1.2 Gbps Full Duplex |
| Forwarding Rates | 0.1488 Mbps/port |
| PoE Standard | IEEE802.3i/802.3u/802.3x |
| PoE Power Supply | 1/2(+),3/6(-) |
| Transmission Distance | 0~250m |
| MAC Address List | 2k |
| Lightning Protection | n/a |
| PoE Power Budget | 48W |
| ESD Protection | Air discharge: 1.5KV Contact discharge: 1.5KV |
| Power Consumption | <5W |
| LED light | Light on: Powering Light off: No Power DIP Switch Light on – VLAN & Extend mode Light off – Normal mode |
| Power Source | Input: 100-240V AC, 50/60Hz built-in power supply |
| Power Light | Green light flash slowly: Searching for device Red light on: Powering but data disconnected Green light flash quickly: Data Transmitting |
| Working Temp | -10°C ~50°C |
| Humidity | 10% – 95%, non-condensing |
| Storage Temperature | -40°C ~70°C |
| Dimension | 202mm x 140mm x 45mm |
